Surge Protection Devices

WAE 25/40 Series

High capacity surge protection for demanding applications

High discharge capacity up to 40 kA
Thermal disconnection safety
Compact DIN rail design
Visual status indication
Download DatasheetRequest Quote
RoHS
TÜV
KEMA
CE

Technical Specifications

TypeType 2 SPD
Nominal Voltage230 / 400 V
Imax (8/20)40 kA
In (8/20)25 kA
Protection Level (Up)≤ 1.5 kV
Response Time≤ 25 ns
MountingDIN Rail

Downloads

DatasheetDownload →
