Surge Protection Devices

WAE 20 Series

Compact and efficient surge protection for standard applications

Compact modular design
Reliable surge protection
Cost-effective solution
Easy installation
RoHS
TÜV
KEMA
CE

Technical Specifications

TypeType 2 SPD
Nominal Voltage230 / 400 V
Imax (8/20)20 kA
In (8/20)10 kA
Protection Level (Up)≤ 1.8 kV
Response Time≤ 25 ns
MountingDIN Rail
